EN 854 R3
| Application |
Medium pressure hydraulic oils, air and water |
| Construction |
|
| Tube |
Synthetic oil resistant rubber |
| Reinforcement |
2 textile braids |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +120 degrees C |
EN 856 4SH
| Application |
Very High pressure hydraulic |
| Construction |
|
| Tube |
Oil resistant Synthetic rubber |
| Reinforcement |
4 high tensile steel wire spirals |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +100 degrees C continuous +125 degrees C |
| Impulse Cycles |
Minimum 400,000 |
| Size |
¾”ID to 2”ID |
SAE 100 R2AT
| Application |
High pressure hydraulic oils, air and water |
| Construction |
|
| Tube |
Synthetic oil resistant rubber |
| Reinforcement |
2 high tensile steel wire braids |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +120 degrees C |
| Impulse Cycles |
200,000 |
| Size |
¼” ID to 4 “ID |
EN 854 R6
| Application |
Low pressure hydraulic oils, air and water |
| Construction |
|
| Tube |
Synthetic oil resistant rubber |
| Reinforcement |
1 textile braids |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +120 degrees C |
EN 856 4SP
| Application |
Very High pressure hydraulic |
| Construction |
|
| Tube |
Oil resistant Synthetic rubber |
| Reinforcement |
4 high tensile steel wire spirals |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +100 degrees C continuous +125 degrees C |
| Impulse Cycles |
Minimum 400,000 |
| Size |
3/8”ID to 2”ID |
Hydraulic High pressure hoses
SAE 100 R1AT
| Application |
High pressure hydraulic oils, air and water |
| Construction |
|
| Tube |
Synthetic oil resistant rubber |
| Reinforcement |
1 high tensile steel wire braids |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +120 degrees C |
| Impulse Cycles |
150,000 |
Super Jack Hose
1000 PSI Working Pressure
| Application |
Hydraulic jack application used in jacking systems |
| Construction |
|
| Tube |
Synthetic oil resistant rubber |
| Reinforcement |
2 high tensile steel wire braids |
| Cover |
Synthetic rubber – abrasion, ozone and weather resistant |
| Temperature Range |
-40 degrees C to +120 degrees C |
|
